CAR A/C COMPRESSOR — KNOW THESE 6 IMPORTANT PARTS!
Read Time:43 Second
❄️🚗 CAR A/C COMPRESSOR — KNOW THESE 6 IMPORTANT PARTS!
The A/C compressor is often called the heart of the automotive air-conditioning system. It circulates refrigerant and helps create the pressure difference needed for cooling.
🔄 1. Pulley – Driven by the engine’s serpentine belt.
⚡ 2. Electromagnetic Clutch – Engages or disengages the compressor when A/C operation is requested.
🔌 3. Electrical Connector – Supplies the control signal/power for the clutch circuit, depending on the compressor design.
🔵 4. Suction Port – Receives low-pressure refrigerant vapor from the evaporator.
🔴 5. Discharge Port – Sends high-pressure refrigerant vapor toward the condenser.
⚙️ 6. Compressor Housing – Protects and contains the compressor’s internal mechanism.
Basic flow:
Evaporator → Suction Port → Compressor → Discharge Port → Condenser → Expansion Device → Evaporator ❄️
💬 Which A/C compressor component would you check first if the car’s A/C stops cooling?
#AutomotiveCarIndia #CarAC #ACCompressor #AutoRepair #AutomotiveEngineering
